What is a PoE Switch and How Does it Work?
A PoE (Power Over Ethernet) switch is a switch that can transmit data signals to some IP-based terminals (such as IP phones, wireless LAN access points AP, network cameras, etc.) without making any changes to the existing Ethernet Cat.5 wiring infrastructure, while also providing DC power to such devices.
PoE technology is also known as a power supply system based on a local area network (POL, Power over LAN) or Active Ethernet (Active Ethernet), and is sometimes referred to as Ethernet power supply.
5-port full Gigabit standard POE switch module development motherboard
It uses existing standard Ethernet transmission cables to transmit data and electrical power at the same time. It is the latest standard specification and maintains compatibility with existing Ethernet systems and users.
The emergence of PoE switches has greatly simplified the power supply and installation process of network equipment, reduced wiring costs, and improved the reliability and flexibility of network equipment. It is widely used in many fields such as home networks, commercial applications, industrial applications, and public facilities.
Working Principle of PoE Switch
The working principle of PoE switch mainly involves the transmission of power and data signals, device detection, power evaluation, power supply control and power-off protection. The following is a detailed introduction to these working principles:
1. Transmission of power and data signals
PoE switch transmits power and data signals together to the device that needs power through Ethernet cable. During the transmission process, the PoE switch connects the power output to the Ethernet port and transmits DC power through the idle wire pair or data core wire in the Ethernet cable. At the same time, the PoE switch is also responsible for transmitting data signals to ensure the normal communication of network devices.
Full Gigabit Standard POE Switch Module for IoT Projects
2. Device detection
When a network device is connected to a PoE switch via an Ethernet cable, the PoE switch will first detect whether the device supports PoE technology. This is achieved by outputting a small voltage to the port and detecting the connection status of the cable terminal. If the device does not support PoE technology, the PoE switch will only transmit data signals and will not supply power. If the device supports PoE technology, the PoE switch will enter the next power evaluation stage.
3. Power evaluation
After detecting the powered device (PD), the PoE switch will classify the PD device and evaluate the power consumption required by the PD device. This is to ensure that the PoE switch can provide enough power to meet the power supply needs of the device while avoiding overload or insufficient power supply.
4. Power supply control
After completing the power evaluation, the PoE switch will start to supply power to the PD device from a low voltage until a stable 48V DC power supply is provided. During the power supply process, the PoE switch will control the voltage and current of the power supply according to the actual needs of the device to ensure the stability and reliability of the power supply. At the same time, the PoE switch will also monitor the power consumption of the PD device to prevent overload or insufficient power supply.
5. Power failure protection
If the PD device is disconnected from the network, the PoE switch will quickly (generally within 300-400ms) stop supplying power to the PD device and repeat the detection process to detect whether the end of the cable is connected to the PD device. This function can protect the PoE switch and PD devices from damage caused by power failure and ensure the stability and security of the network.
Power supply standards and power levels of PoE switches
The power supply standards of PoE switches are mainly based on the IEEE 802.3 series of standards, of which IEEE 802.3af and IEEE 802.3at are the two most commonly used standards.
1. IEEE 802.3af standard
The IEEE 802.3af standard is a new standard based on the Ethernet power supply system PoE. It adds relevant standards for direct power supply through network cables on the basis of IEEE 802.3. The standard stipulates that each PoE port can provide a maximum of 15.4W of power supply, which is suitable for low-power application scenarios.
2. IEEE 802.3at standard
The IEEE 802.3at standard is an extension of the IEEE 802.3af standard, providing a higher power level. The standard stipulates that each PoE port can provide a maximum of 30W of power supply, which is suitable for devices that require higher power, such as wireless access points, network cameras, etc.
In addition, there is the newer IEEE 802.3bt (PoE++) standard, which further expands the power transmission capacity of PoE, with each port transmitting up to 60W-90W, and even up to a power ceiling of 100W. This allows PoE technology to provide reliable power supply for more devices, such as medical equipment, industrial equipment, high-power LED lighting, etc.
IoT Monitoring Solution – IOT Dedicated POE Switch
Applications and advantages of PoE switches
PoE switches are widely used in many fields such as home networks, commercial applications, industrial applications, and public facilities. The following is a detailed introduction to these application scenarios and advantages:
1. Home network
In a home network, a PoE switch can provide power supply for devices such as wireless routers, network cameras, and IP phones. This makes the home network more intelligent and convenient, and users do not need to purchase power adapters or power cables for each device separately, reducing wiring costs and maintenance difficulties.
2. Commercial applications
In commercial applications, PoE switches can power devices such as network cameras, wireless access points, and electronic signs. These devices usually need to be installed in higher places or in locations that are not easy to replace. Using PoE technology can greatly simplify installation and maintenance. At the same time, PoE switches can also provide stable power supply and data communication to ensure the reliability and security of commercial networks.
3. Industrial applications
In industrial applications, PoE switches can power industrial cameras, sensors, controllers and other equipment. These devices usually need to run for a long time and require high reliability. The use of PoE technology can reduce failure rates and maintenance costs, and improve the stability and production efficiency of industrial equipment.
4-port 8-port 12-port 24-core fiber optic terminal box fully equipped with SC/FC/ST/LC splicing box fiber optic pigtail junction box
4. Public facilities
In public facilities, PoE switches can power smart lamps, smart door locks, smart billboards and other equipment. These devices are distributed over a wide area, and the use of PoE technology can simplify wiring and installation. At the same time, PoE switches can also provide stable power supply and data communication to ensure the intelligence and reliability of public facilities.
Selection and precautions of PoE switches
When choosing a PoE switch, users need to consider the following factors:
1. Number of ports and power level
Users need to choose the appropriate number of ports and power level according to actual needs. The number of ports should meet the current and future device connection requirements, and the power level should meet the power supply requirements of the equipment.
2. Power supply standards and compatibility
Users need to understand the power supply standards and compatibility of PoE switches. Different power supply standards have different power levels and transmission distance limits. Users need to ensure that the selected PoE switch matches the power supply standards and compatibility of the connected devices.
3. Brand and quality
Users need to choose well-known brands and high-quality PoE switches. Well-known brands and high-quality PoE switches have better performance and stability, and can provide more reliable power supply and data communication.
4. Price and cost-effectiveness
Users need to choose the right PoE switch according to their budget and needs. Price is not the only consideration, but users need to find a balance between performance and price and choose a cost-effective PoE switch.
When using a PoE switch, users also need to pay attention to the following:
- Ensure that the power supply standards and compatibility of the PoE switch and the connected device match.
- Avoid overload or insufficient power supply to ensure the stability and reliability of the PoE switch.
- Regularly check the operating status and connection status of the PoE switch to detect and solve problems in a timely manner.
Development Trend and Future Outlook of PoE Switches
With the continuous development and popularization of IoT technology, PoE switches, as an important part of IoT infrastructure, will usher in broader market prospects and development opportunities.
485/422/232 3-in-1 optical transceiver POE switch module for IoT projects
The following are the development trends and future prospects of PoE switches:
1. Power level continues to increase
With the increasing number of IoT devices and the increasing power demand, the power level of PoE switches will continue to increase. In the future, PoE switches will support higher power levels to meet the power supply needs of more types of devices.
2. Intelligent and networked trends strengthen
In the future, PoE switches will be more intelligent and networked. By integrating more intelligent functions and network interfaces, PoE switches will be able to provide better device management and data communication capabilities to meet the needs of IoT applications.
3. Security and reliability are strengthened
With the increasing number of IoT applications and the increasing security requirements, the security and reliability of PoE switches will be strengthened. In the future, PoE switches will adopt more advanced security technologies and protection mechanisms to ensure the security and reliability of devices and data.
4. Application scenarios continue to expand
In the future, the application scenarios of PoE switches will continue to expand. In addition to traditional home networks, commercial applications, industrial applications and public facilities, PoE switches will also be used in more emerging fields, such as smart cities, smart transportation, smart homes, etc.
Summary
As a switch that can provide DC power to devices while transmitting data signals, PoE switches have broad application prospects and development opportunities. Through continuous technological innovation and market expansion, PoE switches will provide more reliable, efficient and intelligent power supply and data communication solutions for IoT applications.
