Full Form of POE Switch

“Full Form of POE Switch” actually refers to “Power Over Ethernet Switch”, that is, “Ethernet Power Supply Switch”.

The following is a detailed introduction to POE switch to meet the word count requirements and fully cover its related knowledge.

Definition and function of POE switch

POE switch is a switch that can provide network power supply to remote powered terminals through network cables. It integrates two major functions of network switch and POE power supply, and is a common power supply device in POE power supply system. POE switch not only has the data transmission function of ordinary switches, but also can power network terminals at the same time, eliminating the need for additional power supply wiring.

POE power supply technology principle

POE technology is to provide DC power supply for IP-based terminals (such as IP phones, wireless LAN access points AP, network cameras, etc.) while transmitting data signals without any changes to the existing Ethernet Cat.5 wiring infrastructure. POE technology adds DC power to Ethernet cables, allowing network devices to be directly powered through network cables.

Power supply standards for POE switches

There are three main power supply standards for POE switches, namely IEEE 802.3af (PoE), IEEE 802.3at (PoE+), and IEEE 802.3bt (PoE++).

• IEEE 802.3af standard: defines the maximum power supply power of POE switches as 15.4W, the maximum voltage as 48V, the maximum current as 350mA, and the maximum transmission distance as 100 meters. This standard is suitable for low-power application scenarios.
• IEEE 802.3at standard: provides higher power transmission capability, with a maximum transmission power of 30W. Compared with the IEEE 802.3af standard, PoE+ can provide enough power for more devices, such as IP phones, Wi-Fi access points, IP cameras, etc.
• IEEE 802.3bt standard: is the latest POE switch standard, also known as the PoE++ standard. It allows the eight copper cores of a network cable to be powered at the same time, further expanding the power transmission capacity of POE. The transmission power of each port can reach 60W-90W, and can even reach the power limit of 100W.

Power supply scheme of POE switch

The POE standard defines two methods for using Ethernet transmission cables to transmit DC power to POE-compatible devices:

• Mid-Span method: Use the unused idle wire pairs in the Ethernet cable to transmit DC power, that is, the 1236 line sequence is for data and the 4578 line sequence is for power. The corresponding Endpoint PSE supports Ethernet switches, routers, hubs or other network switching devices with POE functions.
• End-Span method: It is to transmit DC power simultaneously on the core wires used for data transmission. Its power transmission uses a different frequency from the Ethernet data signal, that is, the 1236 line sequence is for data and power at the same time. Mid-span PSE is a special power management device, usually placed together with the switch. It has two RJ45 jacks for each port, one connected to the switch with a short cable, and the other connected to the remote device.

Working process of POE switch

what is a poe switch used for

When a POE switch is deployed in a network, its working process is as follows:

1. Detection: The POE switch outputs a very small voltage at the port until it detects that the connection at the cable terminal is a powered device that supports the IEEE 802.3af standard.
2. PD device classification: After detecting the powered device PD, the POE switch may classify the PD device and evaluate the power loss required by this PD device.
3. Start power supply: During a configurable startup period (generally less than 15μs), the POE switch starts to supply power to the PD device from a low voltage until a 48V DC power supply is provided.
4. Power supply: Provide a stable and reliable 48V DC power to the PD device to ensure that the PD device does not exceed the specified power consumption.
5. Power failure: If the PD device is disconnected from the network, the POE switch will quickly (generally within 300~400ms) stop supplying power to the PD device and repeat the detection process to detect whether the terminal of the cable is connected to the PD device.

Advantages of POE switch

1. Simplified wiring: The POE switch only needs to install and support one cable to transmit data and power at the same time, simplifying the wiring work.
2. Cost saving: Many powered devices need to be installed in places where it is difficult to deploy AC power. POE technology makes these devices no longer require expensive power supplies and the time spent on installing power supplies, thereby saving costs and time.
3. Improved safety: Since there is no direct high-voltage power supply and high-voltage circuit, POE technology improves the safety of use.
4. Easy to manage: When the remote device is connected to the network, the POE switch can remotely control, reconfigure or reset the device through the network.
5. Strong scalability: The power supply distance of POE switch can reach 100 meters, and it supports stacking of multiple devices, using a unified IP address for centralized management, saving address resources.

Application scenarios of POE switch

POE switch is widely used in many fields such as home network, commercial application, industrial application and public facilities. For example, in home network, POE switch can provide power supply for wireless routers, network cameras, IP phones and other devices; in commercial applications, it can power network cameras, wireless access points, electronic signs and other devices; in industrial applications, it can power industrial cameras, sensors, controllers and other devices; in public facilities, it can power smart lamps, smart door locks, smart billboards and other devices.

Precautions for selecting and using POE switch

1. Determine the power of the device: When selecting a POE switch, first determine the maximum power of the powered device to ensure that the switch can provide sufficient power supply.
2. Consider the power supply standard: Choose a suitable switch according to the power supply protocol of the powered device (such as 802.3af, 802.3at or non-standard POE).
3. Pay attention to the power supply distance: The power supply distance of the POE switch is closely related to the quality of the network cable. It is generally recommended to use a standard network cable to ensure the power supply distance and transmission quality.
4. Consider the total power supply power: The total power supply power of the POE switch is an important indicator, which is directly related to how many powered devices can be carried. Therefore, when choosing a switch, consider whether its total power supply power meets the demand.
5. Choose a reliable brand: In order to ensure the quality and stability of the POE switch, it is recommended to choose a switch from a well-known brand and purchase a product with perfect after-sales service.

Technical development and trend of POE switches

With the surge in Internet of Things (IoT) devices and the continuous upgrading of network infrastructure, the technology of POE switches is also evolving continuously. Here are several key trends in the current development of POE switch technology:

1. Higher power output: With the popularization of the IEEE 802.3bt standard, the single-port power output capacity of POE switches has been greatly improved, up to 90W or even 100W. This enables POE technology to support more high-power devices, such as large display screens, video conferencing systems, and industrial automation equipment.
2. Intelligent management: Modern POE switches integrate intelligent management functions, such as remote configuration, monitoring, and troubleshooting through a web interface or dedicated software. Some advanced switches also support SNMP (Simple Network Management Protocol), allowing network administrators to track device status, power consumption, and network traffic in real time.
3. Energy saving and efficiency improvement: In order to reduce energy consumption, the new generation of POE switches adopts more efficient power conversion technology and intelligent power allocation algorithms. For example, the switch can dynamically adjust the power supply according to the actual needs of the connected devices to avoid power waste.
4. Enhanced security: As network security threats increase, POE switches have incorporated more security features into their designs, such as port security, access control lists (ACLs), and encrypted communications. These features help protect networks from unauthorized access and potential network attacks.
5. Integration with wireless networks: Many POE switches now support powering and management of wireless access points (APs), becoming a key component in wireless network deployment. This integration simplifies network architecture, reduces deployment costs, and improves wireless network reliability and coverage.

Installation and maintenance of POE switches

1. Planning before installation: Before installing a POE switch, a comprehensive plan for network topology, device location, and power requirements is required. Ensure that the location of the switch is easy to maintain and that the cable length is within the specified range to avoid signal attenuation and insufficient power supply.
2. Proper wiring: Using standard-compliant network cables (such as Cat5e, Cat6, or Cat6a) is essential to ensure the stability of POE power supply and data transmission speed. Avoid excessive bending or physical damage to the cable to avoid affecting performance.
3. Device compatibility check: Before connecting the device, confirm that all powered devices support the POE standard used, and check whether the power requirements of the device are within the power supply capacity of the switch.
4. Regular maintenance: Regularly check the working status of the POE switch, including port indicators, device temperature, and fan operation. Update the firmware in a timely manner to fix known vulnerabilities and improve performance.
5. Troubleshooting: If you encounter power supply or data transmission problems, first check whether the network cable connection is firm, then check the switch log and statistics to locate the fault point. If necessary, use network analysis tools to assist in diagnosis.

Application cases of POE switches in specific industries

1. Education industry: In schools and universities, POE switches provide power and data transmission for electronic whiteboards, IP phones, and surveillance cameras in classrooms, simplifying wiring and improving teaching and management efficiency.
2. Medical industry: Hospitals use POE switches to power call systems, mobile nursing equipment, and surveillance cameras in wards, ensuring the reliable operation of medical equipment while meeting strict power safety standards.
3. Retail industry: In shopping malls and supermarkets, POE switches provide power for POS machines, electronic price tags and security monitoring equipment, supporting efficient operation management and security monitoring.
4. Hotel industry: Hotels use POE switches to power IP phones, wireless network APs and intelligent control systems in guest rooms, improving guests’ stay experience while reducing operating costs.
5. Smart transportation: In traffic lights, surveillance cameras and vehicle-mounted communication equipment, POE switches provide reliable power and data transmission to support the operation of intelligent transportation systems.

POE switch and green energy saving

In the context of global advocacy of energy conservation and emission reduction, POE switch plays an important role in green energy saving:

• Reduce energy waste: Through intelligent power distribution, POE switch only powers the device when it is actually needed, avoiding the energy waste caused by the device standby in the traditional power supply method.
• Use efficient power supply: Use high-efficiency power conversion module to reduce its own energy consumption and improve energy utilization.
• Support renewable energy: Some POE switches can be combined with renewable energy such as solar energy and wind energy to further reduce carbon footprint.

Market status and prospects of POE switch

Market status:

• Demand growth: With the popularization of IoT devices and the rise of smart buildings, the market demand for POE switches continues to grow.
• Fierce competition: There are many brands and models of POE switches on the market, with large differences in price and function. Users need to consider performance, price and after-sales service when choosing.
• Technology upgrade: Manufacturers continue to launch new products that support higher power and smarter management to meet the high-end needs of the market.

Prospects:

• Market size expansion: It is expected that the market size of POE switches will continue to expand in the next few years, especially in emerging markets and developing countries.
• Technology innovation: With the advancement of technology, POE switches will support higher power output, smarter management and safer communication, further expanding the application field.
• Integration with other technologies: POE technology will be deeply integrated with emerging technologies such as 5G, artificial intelligence and edge computing to promote the development of intelligent networks.

Challenges and solutions for POE switches

Challenges:

• Compatibility issues: Devices from different manufacturers may have compatibility issues, resulting in unstable power supply or data transmission.
• Power limitation: Although IEEE 802.3bt has increased power output, it may still not meet the needs of some high-power devices.
• Safety risks: POE power supply involves power transmission. If there are defects in the equipment or wiring, it may cause safety accidents.

Solution:

• Select standardized products: Give priority to POE switches and devices that meet international standards to ensure compatibility.
• Rational power planning: Rationally plan the power distribution of the switch according to the equipment requirements, and adopt redundant design when necessary.
• Strengthen safety management: Regularly check the equipment and wiring, comply with safety regulations, and prevent overload and short circuit.

Conclusion

As the core equipment of Ethernet power supply technology, POE switches have been widely used in various fields for their advantages of simplified wiring, cost saving, improved safety and easy management.

what is the advantage of poe switch

With the continuous advancement of technology, POE switches will develop towards higher power, more intelligent, safer and more reliable. In the future, POE switches will play a more important role in promoting the construction of the Internet of Things, smart buildings and smart cities.
